Commercial Use Industrial Level 3D Printer PartPro200 X TCS Full Color with Scan Optional Laser Engraving Function CMYK Colors

Commercial Use Industrial Level 3D Printer PartPro200 X TCS Full Color with Scan Optional Laser Engraving Function CMYK Colors

Original Commercial Use Industrial level 3D printer PartPro200 x TCS full color with Scan optional laser engraving function CMYK colors



Full color 3D copy, one step in place

To change the way you work, just use PartPro200 xTCS to scan and print in full color, all at once.

Full-color scanning and printing are integrated into one

Use the built-in 3D scanning module to streamline your modeling process.

Three-dimensional color items for 3D scanning, editing can be directly printed out in full color, one breath!

Easily complete the full color 3D image file

XYZscan Color optimizes your scans.

This software to achieve the best scanning results, with a variety of options to set and edit functions.

Scanned files can be exported to. Obj and. STL file specifications and post – edited using XYZmaker or other software.

Laser engraving function(Optional)

Additional functions: PartPro200 xTCS also has laser engraving function, which can be used on paper, cardboard, leather, wood, plastic and other materials to add more professional flavor to your creative plan. It can be easily used by changing the optional laser carving nozzle.

specifications

Print performance

Printing technology

1. 3D printing is like a Fused Fused Fabrication. 2

Print pattern (layer thickness) : 100-400 microns

Maximum forming size (width x depth x height) : 200 x 200 x 150 mm

XY positioning accuracy: X/Y 12.5 Micron

Z positioning accuracy: Z: 0.0004mm

Printing software: XYZmaker Suite

Supported file format:..

STL, 3 mf, obj,, igs, STP,. The ply,. Amf,. NKG (STL), the 3 cp

Maximum printing speed :180 mm/s

Scanning technology: Laser triangulation ranging technology

Scan size (diameter x height):14*14*14CM

Scanning resolution :5M pixel

Rotary load :≦3 Kg / 6.6 LBS

Output file format:.STL,.obj

consumables

Applicable consumables :3D Color-Inkjet PLA/PLA/Antibacterial PLA/Tough PLA/PETG / *XYZ carbon fiber / * metal PLA (* Optional print head)

Consumable diameter: 1.75mm

Print module

Type of Ink Cartridge (CMYK)

Nozzle diameter: 0.4mm

Number of sprinkler heads :1

The print platform

The print platform

Detachable printing platform (not heated)

Platform autocorrect: Yes

Scanning performance

Scanning resolution: 1.48 mm

Software: XYZscan Color

Ray carving performance

Carved area: 20cm x 20cm

Laser engraving module

optional

Laser wavelength: 406nm + 8nm / -6nm InGaN

Engraving power: 300mW ± 10%

Laser software :XYZengraver

Support image format :.jpg /.png /.gif /.bmp

hardware

Automatic feeding system: Yes

Stepper motor :1.8° HB stepper motor

Display screen: 5-inch touch screen

Language: Multiple languages

Transmission interface :USB 2.0 cable, WiFi 802.11b /g/n, USB portable disk

System requirements

Operating system support

Windows 7/8/8.1/10 (64 bits)

MacOS 10.12/10.13/10.14

minimum

PC: CPU 4th Generation Intel® Core™ i5 Processor or above/RAM: 8GB/hard disk space: 20GB or above MAC: RAM: 8GB/hard disk space: 20GB or above

Operating requirements

Power requirements :100V~240V 240W

Operating temperature :15 ~ 30 °C

Operating humidity :30 ~ 60% RH

Storage temperature – Cartridge :15 ~ 35 °C

Dimension and amp; Weight

Product size (width x depth x height):600 x 581 x 640 mm

Net weight :32 kg

Packing size (width x depth x height):710 x 700 x 820 mm

Transport weight :43 kg

Packing List:

PartPro200 x TCS x 1

Original CMYK x 1

PLA stuff x 2 rolls
