Outdoor sunlight readable 55inch 65inch 84 inch double advertising LCD display kiosk CCTV Monitor Display pc

Outdoor sunlight readable 55inch 65inch 84 inch double advertising LCD display kiosk  CCTV Monitor Display pc

Outdoor sunlight readable 55inch 65inch 84 inch double advertising LCD display kiosk  lcd screen digital signage  LED Displays  CCTV Monitor Display

Specifications:



1.High  brightness  sun  readable  screen(1500nits–2000nits).

2.Waterproof  standard  IP65.

3.  Safety  anti-glare  glass  on  surface.

4.  Unique  cooling  system  can  let  display  working  under  direct  sunlight.

5.  Commercial  designed  for  24/7  operation

6.  Can  be  inbuilt  PC  or  Android  player,  touch  screen  is  optional.



Panel  Size

55″(16:9)  TFT    LCD

Resolution

1920  x1080

Contrast  ratio

‘4000:1

Active  area

1039*584mm

Brightness

1500cd/m2

Viewing  angle

V:178°  ,  H:178°

Build  in  speakers

stereo  sound(10W+10W)

Using  life

50  000  hours

CPU

Android A83T ,Octa-Core, cortex A7,2.0GHz

Memory

1 GB

Nand  flash

8 GB

Storage  port

USB,  SD  card,  (SATA  port  hard  disk  storage  optional)

OS

Android  4.4.4

WiFi

Yes,  inbuild  WiFi(802.11b/g/n)

Other  ports

USB*2,Micro  SD*1,  RJ45*1,  (SATA*1,PCI*1  optional)

Support  video

MPEG1/MPEG2/MPEG4/AVI/VOB/MOV/WMV/DIVX/RM/RMVB,  support  super  HD  2160P  video

Support  picture

JPG/JPEG/GIF/PNG/BMP

Support  Flash

Flash  11,  SWF/FLV/F4V

Support  TXT

TXT/WORD/EXCEL/PDF

Support  Website

HTML/ASP/JSP/PHP

Support  RSS

Internet  RSS  title  and  text,  flip  over/page  turning

Timer

Set  time  on/off  auto

Image  rotate

support  90°,180°,270°  image  rotate

Display  zone

Support  more  than  30  individual  display  zones

Software  upgrade

Support  upgrade  software  by  LAN  or  SD  card



Pictures:







Double side screen wireless video sign displayers 42inch 55inch 65inch HD  wifi players all in one touch screen Led lcd displays











Outdoor waterproof advertising displayers 42inch 55inch 65inch HD advertising players station machine Led lcd displays













UST SO THIN.

DISPLAY UNIQUE CONTENT ON BOTH SIDES.

TESTED IN 50C ENVIRONMENT TEMPERATURE WITH 1200W/M^2 DIRECT SUNLIGHT.

2500 CD/M^2 HIGH BRIGHTNESS.

14 CM THICKNESS.

IP 55.



Available sizes: 43″  55″ 65″

Available colors: Gold, Black



TECH SPECS

OUTDOOR AIR COOLED KIOSK

PANEL

Resolution :  1920 X 1080

Brightness(nits) :  2500 (both sided)

Contrast :  4000:1

Backlight :  vertical led light source

Refresh Rate (ms):  6.5

Viewing angle  : 178° /    178°

Service Life (hours) :  50,000



FUNCTIONAL CHARACTERISTICS

Video Input :  USB×1  , SD×1 , HDMI x 1

USB, SD Supports Video Formats :  support extended .avi , mpg , dat, rm / rmbv , wmv

USB, SD Supports Audio Formats :  support extended .mp3 ,  ,wma ,m4a /aac

USB, SD supports Image Formats :  support extend .jpg / jpeg , bmp , png

Audio Output (w) :  2 x 5

Timing on-off :  Free set Multi-period time

Abnormal Voltage Protection :  Provide detection for internal voltage. It’ll self-closing for protection once it deviates from the standard value range.

Intelligent temperature control system :  Intelligent temperature control function can automatically control the working situation of cooling fan according to environment, to ensure that products can work in environment of high temperature.



POWER SUPPLY

Standby Power Consumption (w) :  2

Shutoff Power Consumption (w):  0.5

Intelligent Optical Sensor :  With automatic function of light sensing. Self-regulation of screen brightness according to the light intensity of environment.

Outdoor Grade :  IP 55,sunlight readable , no blacking

Max Power Consumption(w) : 500(43″)  /  600(55″)  / 850(65″)



PHYSICAL SPECIFICATIONS

Texture of Material :  The outer of display is manufactured from galvanized steel sheets overlaid with low zinc powder and outdoor powder as surface treatment of protection, guaranteed 7 years no fade and no rust , the color of which can be customized.

Full Body Dimension(h x w x d ,  mm) :    1,850 x 723 x 140 (43″ ) , 2,000 X 800  X 140(55″) ,  2,200 X 1050  X 140(65″)

Workshops

Applications:

Packages:



Outdoor sunlight readable 55inch 65inch 84 inch double advertising LCD display kiosk  CCTV Monitor Display pc
