47 55 65inch outdoor FHD 1080p cctv monitor android lcd led advertising pc tv digital signage

47 55 65inch outdoor FHD 1080p cctv monitor android lcd led advertising pc tv digital signage

47 55 65inch outdoor lg 3g 4g wifi dual/double led lcd TFT HD 1080p cctv monitor android advertising pc tv digital signage



 Specification









               LCD

screen  brand

Samsung    /    LG

Size

32 42 47 50″ 55 65

resolution

1920*1080@60HZ

Display  Ratio

16:9

responding  time  (ms)

5

contrast

1000:1

brightness

300cd/m2

viewing  angle

176°/176°(H/V)  60-80  degree

color

16.7M













           Touch

       parameters



Touch  technology

infrared  multi  touch  technology

Touch  type

6  /  10  point  infrared  touch  (  Optical  )

Touch  screen  sensing

fingers,pens,any  other  opaque  objects

resolution

4096*4096  /  32767*32767

Speed

3MS:  8ms

Touch  number

same  position  60000000  times  more

Touch  system  power  supply

USB5.0V  direct  power  supply

operating  system

Windows,  Linux,  Android,  MAC

Detection  Function

support  comes  with  software  testing  function,  can  test  equipment  is  good  or  bad

Remote  upgrade  features

support  for  remote  control  of  the  touch  hardware  (MCU)  function

Positioning  accuracy

less  than  2mm

Sampling  rate

not  less  than  120Hz









   PC  Configuration

CPU

Intel  1037U  /  i3  /  i5  /  i7

Mainboard

Intel  H81

Memory

≥  4G

HDD

500  G

WIFI  (Optional)

Optional

Basic  frequency

350  MHz

processor  frequency

3.3  GHz-4.0GHz

RAM

1GB  DDR3

Graphics

Integrated

Sound  card

Integrated











       TV  Parameters

TV  Standard

NTSC  M/N,PAL  BG/DK/I/H,SECAM  L/L

Multimedia  Formats

MPEG1,MPEG2,MPEG4,H264,RM,RMVB,MOV

USB2.0  Multimedia  Playback

Video/Audio/Picture

USB  System  Upgrading  Online

Support  USB  online  upgrading  function

Resolution

Max  1080P

AUDIO  MODE

B/G,  D/K,  I,  L/L,  M/N

HDMI

V1.3,  720P/1080P

HDCP

V1.1

Scanning  Format

Support  1080P  Video  crisscross  DAS  (Dynamic  Adaptive  Scan  )

Horn

2*10W









             ports

HDMI  Input  port

1  line

VGA  Input  port

1  line

USB  2.0

2

USB  3.0

2

PC  Audio  port

1  line

RJ  45

1  line

LINE-OTU

1  line

Mic-IN

1  line

DC

1  line

Y/pb/cb/pr/cr  inport

1  line

RF  input  ports

1  line

Power  Supplier

Power

AC  110V~240V,50/60HZ



oprating  environment

working  temp

0°C-40°C

storage  temp

-20°C-60°C

Operation  Moisture

20%-80%RH

Storage  Moisture

10%-75%RH

Accessories

Accessories

Driving  CD,  Power  Cable,  Remote  Controller

Weight

Net  weght

56Kg

Gross  weight

65kg

Product Description

















47 55 65inch outdoor FHD 1080p cctv monitor android lcd led advertising pc tv digital signage
