Detector type |
Uncooled FPA microbolometer |
|
Pixel |
640×480 |
|
Pixel pitch |
17μm |
|
NETD |
≤60mk@25℃ |
|
Focal length |
35mm |
|
FOV(±5%) |
17.7°*13.3° |
|
MRTD |
≤0.6℃ |
|
Frame rate |
50HZ |
|
Focus |
Manual |
|
Screen |
Monocular Display 1280*960 |
|
Out-pupil distance |
55mm |
|
Magnification |
10X |
|
Diopter |
adjustable |
|
Brightness/Gain |
Auto/manual |
|
Polarity |
Blackhot/Whitehot |
|
Digital zoom |
x2, x3, x4 |
|
Hotspot tracking |
Yes |
|
Picture in picture |
Yes |
|
Reticle |
Yes |
|
WIFI |
Yes |
|
Built-in |
32G |
|
Storage mode |
Video, picture |
|
Battery type |
Rechargeable battery |
|
Working time |
＞7 hours |
|
Operation temperature |
-20℃~50℃ |
|
Storage temperature |
-40℃~ 70℃ |
|
Color |
Black |
|
Interface |
Standard fixture optional for gun |
|
Protection standard |
IP66 |
|
Weight |
900g |
|
USB-C |
Yes (For charging and data copy) |
|
Detection distance |
Human 1100m / vehicle 2300m |
|
|
|
