Product Description:
The Technical Parameters
Model | RWD150 | RWD100 | RWD50 |
Capacity | 50L | 40L | 20L |
Speed range | 30~2200rpm | 30~2200rpm | 30~2200rpm |
Speed display | LCD | LCD | LCD |
Speed resolution | ±1rpm | ±1rpm | ±1rpm |
Torque | 80N.cm | 60N.cm | 40N.cm |
Overload protection | YES | YES | YES |
Motor protection | YES | YES | YES |
Max viscosity | 80000mPas | 50000mPas | 10000mPas |
Diamter | 0.5-10mm | 0.5-10mm | 0.5-10mm |
Exterior Dimension | 186*83*220mm | 186*83*220mm | 186*83*220mm |
Net weight | 3.0kg | 2.8kg | 2.6kg |
Protect class | IP42 | IP42 | IP42 |
Ambient temp | 5-40C | 5-40C | 5-40C |
Ambient moisture | 80% | 80% | 80% |
RS232 | Yes | Yes | Yes |
Input power | 160W | 120W | 60W |
Output power | 150W | 100W | 50W |
Voltage | AC220V50HZ | AC220V50HZ | AC220V50HZ |
Power | 160W | 130W | 70W |
