Main Features:
*Double- beam optical system.*The Main unit and PC software can independently implement functions of Quantitative;Kinetics;Wavelength Scan; Multi Wavelength; DNA/Protein and Data Printing,PC software can complete the function of data processing.*Suspended posture optical system design, strengthen and thicken the bottom plate to eliminate the vibration or transformation’s impact on the optical system.*24-bit high speed and high precision A/D conversion, and improve the sensitivity of the instrument.*0.5/1.0/2.0/4.0/5.0 bandwidth can be adjusted automatically*The core components are imported with original packaging.*Optical system based on optical system, based on top structure design, top technological requirements and top raw materials.*Standard with PC software
Specification
|
Wavelength Range |
1900-1100nm |
|
Bandwidth |
05./1/2/4/5nm |
|
Wavelength Accuracy |
±0.1nm(D2 656.1NM),±0.3nm |
|
Wavelength Reproducibility |
≤0.1nm |
|
Photometric Accuracy |
±0.2%T |
|
Photometric Repeatability |
≤0.15% T |
|
Straylight |
≤0.03%T |
|
Stability |
±0.0004A/h(500nm) |
|
Baseline Flatness |
±0.0001A |
|
Noise |
±0.0005A |
|
Photometric Range |
0-200%T, -0.3–3A, 0-9999C |
|
Wavelength setting mode |
Automatic |
|
Scanning speed |
High,Middle,Low,Optional |
|
Output |
USB Port |
|
Printer port |
Parallel Port |
|
Display |
LCD(320*240) |
|
Light Source |
Tungsten Halogen Lamp |
|
Detector |
Silicon Photodiode |
|
Power |
110/220 Volts – 50/60 Hz |
|
Dimension |
625x430x210mm |
|
Weight |
28Kg |
