Technical Parameters
Find products on sale
|
Rated voltage
|
380V±15%
|
|||
|
Rated frequency
|
50Hz±2%
|
|||
|
Comensation method
|
Linear compensation
|
|||
|
Response time
|
Full response time≤5ms, Instantaneous time≤100μs
|
|||
|
Switching frequency
|
20kHz
|
|||
|
Compensation effect
|
≥0.99，Compensates for capacitive reacitive reactive and inductive reactive
|
|||
|
Self-loss
|
≤2%
|
|||
|
Efficiency
|
≥98%
|
|||
|
Total harmonic compensation rate
|
≥97%
|
|||
|
Noise
|
≤60dB
|
|||
|
Protection level
|
IP20
|
|||
|
Communication interface
|
RS485, Ethernet, Communication function optional
|
|||
|
Module capacity
|
30Kvar, 50Kvar, 75Kvar, 100Kvar, The same models could be directly connected in parallel
|
|||
|
Cooling method
|
Forced air cooling
|
|||
