Horizontal Wrapping Machine/Flow Wrapper
biscuits, rice Krispies treats, snow cakes, breads, instant noodles, rice noodles, daily necessities, tissues, sanitary towels, industrial parts, paper boxes, tray…
Character
- Dual servo motors and single frequency conversion control, bag length can be set and cut in one step, saving time and film.
- Automatic stop in case of material absence, run film cutter stop, push material automatic make up.
- Temperature control module inside, temperature independent PID control, accurate and suitable for packaging different material.
- Prevent from cutting material function without stop, prevent from cutting material, improve the operating efficiency of the machine and reduce equipment loss.
- Touch interface, easy and quick setting and operating. Self failure diagnosis, clear failure display.
- Positioned stop function, without sticking cutter or wasting film.
- All control is realized though software, easy for function adjusting and technical upgrade.
Option
- Date coder
- Gas flushing device
- UV sterilization
- Alcohol Spraying
- Extruder device
- Stacking device
- Turntable device
Technical data
Model | Speed (pcs/min) |
Max film width (mm) |
Bag size (mm) |
Power (Single phase) |
Dimension (mm) |
Weight (kg) |
FW-140 | and lt;500 | 140 | L: 45-80 W: 60-100 H:6-12 |
220V 50-60Hz 3.5kw |
3800x1350x1450 | 980 |
FW-240 | 30-220 | 240 | L: 75-190/150-350 W: 40-100 H: and lt;35 |
220V 50-60Hz 2.8kw |
3900x840x1330 | 600 |
FW-280 | 30-220 | 280 | L: 85-210/170-380 W: 40-125 H: and lt;45 |
220V 50-60Hz 2.8kw |
3900x840x1330 | 600 |
FW-320 | 30-220 | 320 | L: 110-250/200-420 W: 40-150 H: and lt;55 |
220V 50-60Hz 2.8kw |
3900x840x1330 | 600 |
FW-450 | 20-200 | 450 | L: 115-480 W: 80-215 H: 80 |
220V 50-60Hz 4.5kw |
3900x840x1330 | 700 |
FW-600 | 20-100 | 600 | L: 115-230 W: 40-280 H: 80 |
220V 50-60Hz 4.5kw |
3900x840x1330 | 700 |
