High Precision Automatic Small Metal Parts, Hardware Accessories Packaging Machine

High Precision Automatic Small Metal Parts, Hardware Accessories Packaging Machine

The price is for reference only, the finial cost of the machinery and freight will be difference due to the configurations and addresses.

Ship by sea, much cheaper! Contact us now!

Copy our official link:TodayMachine.com

Standard

  • Intuitive operator guidance on the touch screen panel

  • Integration of all identification systems

  • Printed mark identification and amp; measurement of bag lengths

  • Use of different heat sealing and welding instruments

  • Minimal time required when changing rolls

  • Stop when film roll end. Detect the fault automatically.

  • Seal tight, no leaking.

  • Power supply: 110V, 120V, 220V, 240V. 50Hz, 60Hz.

Available option

  • Stainless steel and Paint version

  • Date and amp; batch printer

  • Date embossing system

  • Gas-flushing system

  • Exhaust sponge system, packet less/more air inside

  • Easy tearing notch

  • Round and Euro-hole punch, carrying handle punch

  • Numerical control cutter system, 1-99 packet

  • Frequency control system, less noise and amp; save energy

  • Full closed protective cover

  • Auto shutdown trigger when protective cover opens

Granule/Powder Packaging Machine with Volumetric Cup System

Grain, Snack, Sugar, Spice, Rice, Popcorn, Seed, bean, Milk powder, Sliced Vegetable, Detergent, powder, Ground coffee, instant coffee, Talcum powder, desiccant…

Model

VFFS-280C

VFFS-280C-PLUS

VFFS-450C

VFFS-600C

Film width

Max 300mm

Max 320mm

Max 420mm

Max 580mm

Bag size

L:30-175/190/210mm

W:25-145mm

L:40-240/280/380mm

W:25-140mm

L:50-275/295mm

W:60-195mm

L:50-380mm

W:60-280mm

Output

40-90 pcs/min

30-60 pcs/min

15-40 pcs/min

10-30 pcs/min

Bag type

Pillow seal

3 side seal

4 side seal

gusset seal

pyramid seal

Pillow seal

3 side seal

4 side seal

gusset seal

Pillow seal

3 side seal

4 side seal

gusset seal

Pillow seal

3 side seal

4 side seal

gusset seal

Packing range

(ml≠g)

1-20g

10-100g

Powder:

22-220ml

Grain:

0.5-3ml

3-15ml

15-90ml

30-180ml

20-130g

50-250ml

100-500g

100/500-1000g

300-800ml

400-1000ml

100-500g

100/500-1000g

Dimension

1200x1000x1750

mm

1200x1000x2000

mm

1300x1100x2100

mm

1500x1300x2200

mm

Total power

1.5KW

1.5KW

2.6KW

3KW

Weight

350kg

400kg

450kg

520kg

Powder Packaging Machine with Auger System

Flour, Cocoa powder, Coffee powder, Cocoa powder, Spice, seasoning, pepper,Chemical powder, Washing powder, Milk powder, protein powder…

Model

VFFS-280A

VFFS-280A-PLUS

VFFS-450A

VFFS-600A

Film width

Max 300mm

Max 300mm

Max 400mm

Max 580mm

Bag size

L:30-175mm

W:28-140mm

L:40-190/240/275mm

W:20-140mm

L:50-275/295mm

W:60-195mm

L:50-380mm

W:60-280mm

Output

30-60 pcs/min

30-60 pcs/min

15-36 pcs/min

10-30 pcs/min

Bag type

Pillow seal,

3 side seal

4 side seal

gusset seal

pyramid seal

Pillow seal,

3 side seal

4 side seal

gusset seal

Pillow seal,

3 side seal

4 side seal

gusset seal

Pillow seal

gusset seal

Packing range

(ml≠g)

0.3-0.6ml

0.5-3ml

2-10ml

8-20ml

15-90ml

20-100ml

50-200ml

1-100g(10L hopper)

1-350g(25L hopper)

1-500g(50L hopper)

50-200ml

100-500ml

200-1000ml

50-200ml

100-500ml

200-1000ml

500-2000ml

Power

1.8KW

2KW

2.6KW

3KW

Dimension

1200x1000x1660

mm

1200x1000x1900

mm

1200x110x2000

mm

1500x1300x2200

mm

Weight

350kg

400kg

450kg

520kg

Liquid/Paste Packaging Machine with Pump volume control system

Juice, Honey, Ketchup, Peanut butter, Garlic sauce, Milk, condensed milk, Shampoo, gel, emulsion, lotion, Liquid detergent, liquid soap, oil, cream, glue …

Model

VFFS-280LP

VFFS-280LP-PLUS

VFFS-450LP

VFFS-600LP

Film width

Max 300mm

Max 320mm

Max 420mm

Max 580mm

Bag size

L:30-175/190/210mm

W:18-140mm

L:40-240/275/380/430mm

W:20-140mm

L:50-275/295mm

W:60-195mm

L:50-380mm

W:60-280mm

Output

30-60

pcs/min

30-60

pcs/min

15-30

pcs/min

10-30

pcs/min

Bag type

Pillow seal

3 side seal

4 side seal

pyramid seal

Gusset seal

Pillow seal

3 side seal

4 side seal

Pillow seal

3 side seal

4 side seal

Gusset seal

Pillow seal

3 side seal

4 side seal

Gusset seal

Packing range

(ml≠g)

5-45ml

10-100ml

20-150ml

50-280ml

25-280ml

50-500ml

200-900ml

50-280ml

100-550ml

200-900ml

200-1100ml

200-1400ml

50-280ml

100-550ml

200-900ml

200-1100ml

200-1400ml

Dimension

1150x1000x1760

mm

1100x1000x2000

mm

1400x1100x2150

mm

1500x1300x2300

mm

Power

2KW

2.2KW

2.6KW

3KW

Weight

350kg

400kg

460kg

550kg

Flowability Liquid Stick Packaging Machine

Juice, Water, Jelly, Ice pop, ice lolly…

Model

VFFS-280LS

Film width

Max 100mm

Bag size

L: 40-275/295mm

W: 10-30mm

Output

40-80 pcs/min

Bag type

Stick seal

Range

Gravity with Level Control10-150ml

Power

1.2KW

Dimension

(L*W*H)

1100x900x1900mm

Weight

380kg

Irregular Products Packaging Machine with Skip Bucket

Irregular items

Model

VFFS-280B

VFFS-280B-PLUS

VFFS-450B

VFFS-600B

Film width

Max 300mm

Max 300mm

Max 420mm

Max 580mm

Bag size

L:40-175/190/210mm

W:30-140mm

L:40-240/280/380mm

W:30-140mm

L:50-275/300mm

W:60-195mm

L:50-380mm

W:60-280mm

Output

30-70

pcs/min

30-60

pcs/min

15-40

pcs/min

10-30

pcs/min

Bag type

Pillow seal

3 side seal

4 side seal

gusset seal

pyramid

Pillow seal

3 side seal

4 side seal

gusset seal

Pillow seal

3 side seal

4 side seal

gusset seal

Pillow seal

gusset seal

Packing range

(ml≠g)

0-100g

0-100g

100-500g

100-1000g

Power

1.8KW

1.8KW

2.6KW

3KW

Dimension

1100x1200x1750mm

1100x1200x2000mm

1200x1100x2100mm

1500x1300x2200mm

Weight

380kg

420kg

450kg

550kg

Tablet Packaging Machine with Counting System

Pill, Camphor pills, Round subject, Milk chewable tablets, Walnut, Chocolate beans, candy …

Model

VFFS-280CT

VFFS-280CT-PLUS

VFFS-450CT

Film width

Max 300mm

Max 300mm

Max 420mm

Bag size

L:30-175mm

W:60-145mm

L:50-190/210/240/275mm

W:60-145mm

L:50-280mm

W:60-195mm

Output

30-76 pcs/min

30-60 pcs/min

15-36 pcs/min

Bag type

Pillow seal

3 side seal

4 side seal

gusset seal

Pillow seal

3 side seal

4 side seal

gusset seal

Pillow seal

3 side seal

4 side seal

gusset seal

Packing range

1-100 tablets

1-100 tablets

1-100 tablets

Dimension

1100x1000x1760

mm

1100x1000x2000

mm

1200x1100x2100

mm

Total power

2KW

2KW

2.6KW

Weight

350kg

400kg

450kg

Powder/Granule+Liquid/Paste 2 in 1 Packaging Machine

C: Volumetric cup system(for granule/powder)

A: Auger system(for powder)

LP: pump system(for liquid/paste)

Model

Range

Bag

Length

Width

(mm)

Speed

(b/min)

Bag type

Weight

(kg)

Dimension

(mm)

VFFS-280

C+LP

Granule+liquid/paste

C:1-20g

10-100g

LP:5-45ml

10-100ml

L: 30-175

W:20-145

20-60

Pillow

3 side

4 side

gusset

400

1100×1250

x1700

VFFS-280

A+LP

Powder+liquid/paste

A:2-10ml

8-20ml

15-90ml

20-100ml

50-200ml

LP:5-45ml

10-100ml

L: 30-175

W:20-145

20-60

Pillow

3 side

4 side

gusset

400

1100×1250

x1700

VFFS-280

C+LP-PLUS

Granule+liquid/paste

C:1-20g

10-100g

LP:25-280ml

50-500ml

L:40-190/240/275

W:20-140

30-60

Pillow

3 side

4 side

440

1000×1300

x1700

VFFS-280

A+LP-PLUS

Powder+liquid/paste

A:1-100g

1-350g

1-500g

LP:25-280ml

50-500ml

L:40-190/240/275

W:20-140

30-60

Pillow

3 side

4 side

440

1000×1300

x1700

VFFS-450

C+LP

Granule

+liquid/paste

C:100-500g

500-1000g

LP:10-100ml

50-280ml

50-500ml

L:50-275/295

W:60-195

10-30

Pillow

gusset

480

1200×1300

x2000

VFFS-450

A+LP

Powder

+liquid/paste

A:100-500g

500-1000g

LP:10-100ml

50-280ml

50-500ml

L:50-275/295

W:60-195

10-30

Pillow

gusset

480

1200×1300

x2000

Liquid + Paste 2 in 1 Automatic Packaging Machine

Liquid/oil+Paste/Sauce

Model

VFFS-280L+P

VFFS-280L+P-PLUS

VFFS-450L+P

Film width

Max 310mm

Max 310mm

Max 410mm

Bag size

L:30-175/190/210mm

W:10-145mm

L:40-240/280/380mm

W:15-140mm

L:50-275/295/380mm

W:60-195mm

Output

20-60

pcs/min

20-60

pcs/min

15-35

pcs/min

Bag type

Pillow seal

3 side seal

4 side seal

Pillow seal

3 side seal

4 side seal

Pillow seal

3 side seal

4 side seal

Packing range

5-45ml

20-100ml

50-280ml

5-45ml

5-100ml

50-280ml

100-550ml

100-1000ml

50-280ml

100-550ml

200-900ml

100-1000ml

Dimension

1100x1000x1760mm

1100x1000x1900

mm

1200x1100x2000mm

Power

2KW

2.4KW

2.7KW

Weight

380kg

420kg

460kg

Multi Lane 4 side seal Packaging Machine

Liquid/Paste.

Application

Mainly Packaging the liquid or paste in small sachet at high speed, such as shampoo, lotion, hand washing, liquid soap,liquid flavors, juice, oil, jam, honey etc.

Main Features

The multilane four side sachet packing Machine is optional for complete or partial stainless steel and all out equipment have received the CE certificate.

Program controller, advanced inverter, and imported power switch.

English screen display, operation is simple and reliable.

Stainless steel build, food grade standard.

More lanes available.

Model

VFFS-M4-500LP

VFFS-M4-600LP

VFFS-M6-500LP

VFFS-M6-600LP

Lane

4

4

6

6

Max Film width

500mm

600mm

500mm

600mm

Bag type

4 side seal

4 side seal

4 side seal

4 side seal

Bag size

L:30-150mm

W: 25-57mm

L:30-150mm

W: 25-75mm

L:30-150mm

W: 25-38mm

L:30-150mm

W: 25-50mm

Range

1-10ml

10-100ml

1-10ml

10-100ml

1-10ml

10-100ml

1-10ml

10-100ml

Speed

100-160

bag/min

100-160

bag/min

160-240

bag/min

160-240

bag/min

Power

3kw

3kw

3kw

3kw

Power  supply

220V 50Hz

110V 60Hz

220V 50Hz

110V 60Hz

220V 50Hz

110V 60Hz

220V 50Hz

110V 60Hz

Dimension

990x1150x1800

mm

1100x1150x1800

mm

990x1150x1800

mm

1100x1150x1800

mm

Weight

400kg

420kg

400kg

420kg

Granule/Powder Packaging Machine with Linear Weigher

Grain, Snack, Rice, Popcorn, Seed, bean, Sugar, salt, Sliced Vegetable, Cornmeal …

Model

Film width

(mm)

Bag size

(mm)

Speed

(pcs/min)

Range

Power

Weight

(kg)

Size

(mm)

VFFS280

+DCS2

Max 320

L:40-175/275

W:20-145

20-40

10-100g

10-300g

10-600g

2kw

300

1100x1000x1900

VFFS280

+DCS4

Max 320

L:40-175/275

W:20-145

40-70

10-100g

10-200g

2.3kw

390

1100x1000x1900

VFFS450

+DCS2

Max 420

L:50-275

W:60-195

10-30

10-300g

100-1000g

3.3kw

400

1200x1100x2000

VFFS450

+DCS4

Max 420

L:50-275

W:60-195

20-50

10-200g

100-1000g

3.5kw

420

1200x1100x2000

Automatic Collar type Packaging Machine

Grain, Powder, Liquid, Paste/Sauce

Model

VFFS-FL320

VFFS-FL420

VFFS-FL520

Film width

(mm)

Max 320

Max 420

Max 520

Bag size

(mm)

L:50-180

W:45-140

L:80-220

W:70-200

L:80-400

W:50-250

Output

(pcs/min)

50-90

30-80

10-50

Bag type

3 side seal

4 side seal

Pillow seal

Gusset seal

3 side seal

4 side seal

Pillow seal

Gusset seal

Pillow seal

Gusset seal

Filling system

Volumetric Cup

Auger

Pump

Weigher

Volumetric Cup

Auger

Pump

Weigher

Volumetric Cup

Auger

Pump

Weigher

Air pressure

0.65mpa

0.65mpa

0.65mpa

Air consumption

0.3m3/min

0.3m3/min

0.3m3/min

Size

(mm)

1080x980x1880

950x1500x2050

1317x1115x1443

Weight

400kg

440kg

750kg


Teabag/coffee  pod/custom shape sachet  packaging  machine

By filter paper, plastic, nylon, non woven…

Application

  • Small Automatic Tea Bag Packing Machine is suitable for the dual bag packing of small grain or powder materials, such as tea leafs, medicinal tea and healthy teas,

Feature

This machine is hot-sealed, automatic and multifunction packing equipment.

The main characteristic of this equipment is it can molding in one time to protect the material from the direct contact with workershands and improve the efficiency.

The inner bag is filter paper, tagging with thread and label automatically.

The outer bag is composite paper (including various kinds of composite membrane hot sealable such as paper/plastic, plastic/plastic, plastic/aluminum/plastic, paper/aluminum/plastic.)

The most advantage is, the capacity, the inner bag and outer bag can be adjuster flexibly, and the size of the inner and outer bag also can be adjuster according to the requirement of the customer to get the perfect effect.

Model

VFFS-R

VFFS-UL

VFFS-PTL

VFFSL-TL

VFFS-TLO

Function

Coffee Pod

customized shape

Ultrasound Packet

Pyramid bag

+thread

+Label

Inner bag

+thread

+Label

Inner bag

+thread

+Label

+outer  bag

Packing material

Filter paper

Non-woven

Plastic

Non-woven

Nylon

PLA

Non-woven

PET

Filter paper

Plastic

Filter paper

Plastic

Output

(Bags/min)

30-60

20-40

40-60

30-60

20-50

Max.dosage

1-10g

10-50g

1-20g

10ml

15ml  (5g)

15ml  (5g)

Film width

(mm)

Max 260

120 140 160

Inner 100-160

Inner 100-160

Outer 120-200

Bag

(L*W;mm)

Round

Custom design

(50-180)*(50-130)

Pyramid

(40-80)*(60-80)

3 side

(50-70)*(50-80)

3 side

(50-70)*(50-80)

Label/Tag

(L*W;mm)

(20-40)*(40-55)

(20-40)*(40-55)

Power

(Kw)

1.5

2

2.2

3

3.5

Weight

(Kg)

380

400

480

450

500

Strong Quality with Long-usage Life, Not the Cheap Ones.

We(Today Machine Team) don’t sell low quality with cheap tech then always repair and cuasing troubles. We are more up to stable machine with mature tech and amp; reliable program for clients under trustful relationship for lifetime.

High Precision Automatic Small Metal Parts, Hardware Accessories Packaging Machine
