Liquid/Paste/Sauce Packaging Machine with Pumping System
Juice, Honey, Ketchup, Peanut butter, Garlic sauce, Milk, condensed milk, Shampoo, gel, emulsion, lotion, Liquid detergent, liquid soap…
Standard
- Closed sealer housing
- Intuitive operator guidance on the button/touch panel
- Integration of all identification systems
- Printed mark identification and amp; measurement of bag lengths
- Use of different heat sealing and welding instruments
- Minimal time required when changing rolls
- Stop when film roll end. Detect the fault automatically.
- Seal tight, no leaking.
Available option
- Stainless steel and Paint version
- Display panel: Touch screen
- Date and amp; batch printer
- Date embossing system
- Exhaust sponge system, less air inside the packet
- Easy tearing notch
- Round and euro-hole punch, carrying handle punch
- Insulation and stirring system
- Numerical control cutter, 1-99 packet
- Flat bottom package with center seal
- Frequency control system, less noise and amp; save energy
- Power supply: – 110V, 120V, 220V, 240V. – 50Hz, 60Hz.
- Bottom holding set
Technical parameter
| Model L: Liquid P: Paste |
VFFS-280L/P | VFFS-450L/P | VFFS-520L/P |
| Film width | Max 300mm | Max 420mm | Max 500mm |
| Bag size | L: 40-175mm W:10-140mm |
L:50-275/295mm W:60-195mm |
L:50-275/295mm W:60-240mm |
| Output | 30-70pcs/min | 15-36 pcs/min | 10-30pcs/min |
| Bag type | Pillow seal 3 side seal 4 side seal gusset seal pyramid seal |
Pillow seal gusset seal |
Pillow seal gusset seal |
| Packing range (ml≠g) |
5-45ml 10-100ml 20-150ml 50-280ml |
50-280ml 100-550ml 200-900ml 200-1100ml 200-1400ml |
50-280ml 100-550ml 200-900ml 200-1100ml 200-1400ml |
| Dimension | 1100x990x1660mm | 1200x1100x1900mm | 1200x1100x1900mm |
| Power | 2KW | 2.6KW | 2.8KW |
| Weight | 280kg | 360kg | 380kg |
