Description
1.designed on the basis of this company series products with extra functions increased. The product is simple and convenient in operation,error correction, machine cleaning and maintenance.
2.Widely used for filling various kinds of highly viscous fluid in the industries of daily chemicals, foodstuffs, pharmaceutics and oil.
3.With two synchronous filling heads, quick and accurate filling possible With Taiwans pneumatic elements and electrical control parts adopted, its performance is stable.
4.The cylinders and pistons are made of 304L stainless steel and lined with PTFE, conforming to GMP.
5.Quality guaranteed by Taiwans PLC, touchable screen and frequency inverter, and electrical elements.
6.Compact design, attractive appearance, convenient installation and filling adjustment, no missed filling and accurate filling dosage with a counter provided.
7.Closure head preventing leakage and wiredrawing, filling elevating system preventing high froths, bottle top positioning system and liquid level control system provided.
This machine need customized your bottle size.pls feel free to contact us .thank you
Parameter
Model | 2heads | 4heads | 6heads |
Voltage | 110V/220V, 50HZ/60HZ, 800W | ||
Filling range | 5-100ml,10-28ml,20-500ml,50-1000ml,500-2800ml,1000-5000ml | ||
Filling speed | 10-40bottles/min | 20-50bottles/min | 30-70bottles/min |
Filling precision | 1% | ||
Air pressure | 0.5-0.7Mpa | ||
Weight | 220kg | 260kg | 300kg |
Dimemsion (L*W*H) | 210*86*146cm | 260*86*146cm | 320*86*146cm |
