Automatic L Type Sleeve POF Shrink Wrapping Packaging Heat Sealing Machine For Business

Automatic L Type Sleeve POF Shrink Wrapping Packaging Heat Sealing Machine For Business






Shrink Film Sealing Cutting Machine

POF/PE Film Packaging.


Application

Mainly used in the production of packaging for pharmaceutical, food, beverage, stationery, printed matter, cosmetics, gifts, electronic products, toys and other products.

Feature

This machine has high working efficiency, automatic film feeding and punching, automatic film sealing and cutting, only need to manually adjust the film guiding system and manually adjust the feeding conveying platform for products of different widths and heights. The automatic sealing and shrinking packaging machine is also suitable for multi-piece wrapping and tray packaging, and can also be used with the automatic packaging line, which is the first choice for sealing and shrinking packaging.

Technical

Model FQL-450 FQL-550 FQB-450 FQB-550 FQB-650 FQB-750
Type L bar L bar Side seal Side seal Side seal Side seal
Packing width
(Max)
350mm 450mm 350mm 450mm 550mm 650mm
Packing length
(Max)
550mm 650mm unlimited unlimited unlimited unlimited
Packing height
(Max)
120mm 120mm 150mm
190mm
150mm
200mm
150mm
250mm
150mm
250mm
Speed 15-30
pcs/min
15-30
pcs/min
15-30
pcs/min
10-25
pcs/min
10-20
pcs/min
10-20
pcs/min
Temperature 0-400℃ 0-400℃ 0-400℃ 0-400℃ 0-400℃ 0-400℃
Air pressure 0.5MPA 0.5MPA 0.5MPA 0.5MPA 0.5MPA 0.5MPA
Voltage 220V
50-60hz
1.25kw
220V
50-60hz
1.25kw
220V
50-60hz
1.5kw
220V
50-60hz
1.5kw
220V
50-60hz
1.5kw
220V
50-60hz
1.5kw
Dimension 1700*930*1460
mm
1740*1020*1460
mm
1700*920*1460
mm
1740*1020*1460
mm
1960*1120*1460
mm
2120*1180*1470
mm
Weight 310kg 320kg 300kg 500kg 600kg 660kg





Shrink Film Wrapper

Food, beverage, medicine, video/audio products, metal ware. Cosmetics, books, toy, plastic and electronic products.

Application

Mainly used in the production of packaging for pharmaceutical, food, beverage, stationery, printed matter, cosmetics, gifts, electronic products, toys and other products.

Feature

Infinitely variable transmission, stable and low noise

Quartz heating tube, adjustable temperature from 0-300℃

Conveyor driven by powerful DC motor, with heavy load capacity

Continuous working available

Fit for PVC, PP and POF material film

Technical parameter

Model BS-2615 BS-4020 BS-4525 BS-6535
Conveying way Web/
Chain
Web/
Chain
Web/
Chain
Web/
Chain
Electric 220V 220V/380V 380V 380V
Power 4.8KW 6.8KW 7KW 12KW
Conveying Temperature 0-300℃ 0-300℃ 0-300℃ 0-300℃
Speed 0-10m/min 0-10m/min 0-10m/min 0-10m/min
Shrinking Oven
(Max Shrink Size)
750x260x150mm 800x400x200mm 900x450x250mm 1200x650x350mm
Max Loaded Weight 5kg 8kg 10KG 10KG
Machine Weight 40kg 43kg 110kg 130kg
Machine Size 1000x460x600mm 1100x600x640mm 1200x650x830mm 1600x850x830mm

Temperature for different materials

Material PVC PP POF
Thickness 0.02-0.06mm 0.02-0.04mm 0.03-0.1mm
Heating time 5-10s 6-12s 8-16s
Shrinking Temperature 110-130℃ 130-170℃ 130-170℃

Strong Quality with Long-usage Life, not the  Cheap Model.
We Don’t Sell Low Quality   and amp; Cheap Machines Then Always  Repair.
