IN STOCK

In package include:

1) pcs Programmer SVOD Ver. 3

2) pcs USB Connection cable

3) pcs Extended board of ports for keyboard module

4) Flex cables: 34pin, 32pin, 30pin, 26pin (all cables what you see in picture).

5) ZIP CLIPS

6) Socket 150mil (1pcs )+ 200mil (1pcs)

7) SPI ROM cable 1pcs – ((U6100+U6100+U5100 ( Hirose 12 + Hirose30 + Molex30))

8) Schematics + boards files

9)Video Tutorial and software

———————————————–

SPI ROM cable – Comptible Macbook’s list until 2017 year if you use SVOD programmers:

A1534 emc 2746 820-00045, A1534 emc 2991 820-00244, A1534 emc 3099 820-00687, A1370 emc 2393 820-2796, A1370 EMCXXXX 820-2955, A1370 EMCXXXX 820-2955, A1465 emc 2558 820-3208, A1465 emc 2631 820-3435, A1465 emc 2924 820-00164, A1304 EMCXXXX 820-2375, A1304 EMCXXXX 820-2375, A1369 emc 2469 820-3023, A1466 emc 259 820-32509, A1466 emc 2632 820-3437, A1466 emc 2925 820-00165, A1466 emc 3178 820-00165, A1425 emc 2512 820-3462, A1502 emc 2678 820-3536, A1502 emc 2678 820-3476, A1502 emc 2875 820-3476, A1502 emc 2835 820-4924, A1398 emc 2512 820-3332, A1398 emc 2673 820-3332, A1398 emc 2746 820-3662, A1398 emc 2876 820-3662, A1398 emc 2745 820-3787, A1398 emc 2881 820-3787, A1398 emc 2909 820-00138, A1398 emc 2910 820-00163, A1398 emc 2910 820-00426, A1708 EMCXXXX 820-00361, A1708 emc 2978 820-00875, A1708 emc 3164 820-00840, A1706 emc 3071 820-00239, A1706 emc 3163 820-00923, A1707 emc 3072 820-00281, A1707 emc 3162 820-00928, A1283 emc 2264 820-2366,A1283 emc 2336 820-XXXX, A1347 emc 2364 820-2577, A1347 emc 2442 820-2993, A1347 emc 2442 820-3059, A1347 emc 2442 820-3017, A1347 emc 2570 820-3227, A1347 emc XXXX 820-3228, A1347 emc 2840 820-5509

———————————————–

SVOD V3 programmer is a universal programmer for various microcircuits.

As you know you can program different kinds of chips such as: SPI, I2C, ONE WIRE, NAND, NAND SPI, NOR, EMMC, JTAG, UART, ENE, MEC, ITE, NUVOTON, parallel synchronous and asynchronous protocols. Automatic detection of “bad contact” when connecting chips.

Supported:

KB9010/KB9012/KB9016/KB9022

NPCE288N/NPCE388N

ITE8386/8580/8585/8586/8587/8985/8987

MEC1609/1619/1632/1633/1641/1650/1651/1653/5035/5045/5055/5045/5075/5085

EPF011/021/035/036/037

Specifications:

– port of connection to the computer: usb 2.0 high speed,

– connection of microcircuits: zif 48,

– number of input /output ports: 48,

– power supply voltage: 1.2V / 1.8V / 2.5V / 3.3V

You can buy a brand new programmer / Tested 100% .

The mode of displaying POST codes of the laptop motherboard is implemented. Choose the software in the online base of your motherboard, download, select it in the choice of motherboard, connect the motherboard with a loop to the keyboard connector, and read the post codes by running the software in read mode of POST codes.

MANY FLASHING FILES IN DATABASE FOR FREE

PDF FILES

ENE_KB9012_on_Precision_M3800_LA-9941P.pdf

ENE_KB9022_on_Thinkpad_S1_Yoga_12_LA-A342P_.pdf

In-Circuit_Serial_Programming_with_SVOD3.pdf

ITE_IT8586_on_Thinkpad_Yoga_2_Pro_VIUU3_NM-A074.pdf

MEC5075_on_Latitude_E7440_LA-9591P.pdf
