Item |
Outdoor full color led display |
|
Model Number |
P10 |
|
Pixel Pitch |
10mm |
|
Pixel Density(dots/m⊃2;) |
10000 |
|
Pixel Configuration |
RGB |
|
LED Type |
DIP346 |
|
Module size(mm) |
160*160 |
|
Module Resolution(dots) |
16*16 |
|
Min.Viewing Distance(m) |
≥8 |
|
Brightness(cd/m⊃2;) |
≥7500 |
|
Viewing Angle(degree) |
≤180° |
|
Average Power Consumption(w/m2;) |
180 |
|
Scan Mode |
1/4 |
|
Protection Level |
IP65 |
|
Cabinet Size(mm) |
960*960 |
|
Color Temperature |
The brightness of R.G.B.is adjustable according to software 100level;Color temperature is adjustable in terms of detailed requirements |
|
Input Voltage |
AC220 V/50HZ or AC 110V/60HZ |
|
Refresh Rate |
LED screen refresh frame freauency recommended is no less than 1200HZ(recommended) |
|
Color |
64g color(on the condition of 4096 gray scale) |
|
Horizontal/Vertical viewing angle |
160° |
|
Gray Scale |
Recommended 14BIT |
|
Effective Communication Distance(without relay) |
Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
| Power Supply | Domestic Power Supply |
| Printed Circuit Board(PCB) | 2 Layer |
| Cabinet weight | 55KG |
| Cabinet resolution | 96*96 dots |
| Cabinet | Iron Cabinet |
| Warranty | 3 Years |
To dear buyers, for detailed shipping charges, please contact the seller, Thank you!
1. With professional technical and development team, we are a direct Factory specialized in led display control card, led display module, power for led display, led display, and other led display accessories etc.
2. With more than 10 years’ experience, modern production and test equipment,perfect enterprise management system,high quality research and management team, high quality led display controller, all above make us become popular supplier.
3. With our high quality and service our products have been exported to various countries and regions in Southeast Asia, Australia, Europe and America etc.
We also supply Flight Case
if you need pls contact us.
Shipping by Express
1. We Ship to Worldwide.
2. Items are shipped from China via EMS, UPS, FedEx, DHL, TNT and airmail (with tracking number) etc.
3. Delivery time depends on the courier company ,the destinations, the local customs and other factors; We hope it arrive on time, but this international delivery shipping time will be highly depends on the courier company and local customs, hope you can understand if there are any shipping delay caused by above reasons.
Or by Sea
If you want to deliver the led display board by sea pls tell us, we will quote you the ocean freight.
