HD P3 Indoor led poster video display function full color advertising store led display

HD P3 Indoor led poster video display function full color advertising store led display

HD P3 Indoor led poster video display function full color advertising led mirror screen

Specification:

Pixel  structure SMD  3  IN  ONE  2121  black  leds  with  mask
Pixel  pitch 3mm
Module  resolution 64*64
Module  size(mm) 192(W)*192(H)
Module  weight(KG) 0.3
Module  power  consumption(W) 40
Module  quantity 3(W)*10(H)
Display  resolution 192(W)*640(H)
Frame  size(mm) 656(W)*2000(H)*  100(D)
Display  area(m2) 1.132
Cabinet(KG) 44
Pixel  density(dots/m2) 111111
Electronic  drive  solution ICN2153+ICN2102
Brightness(CD) 800~900
Color  temperature 3200-9300,  adjustable
Horizontal  viewing  angle(Deg) 140
Vertical  viewing  angle(Deg) 120
Luminous  point  center  distance  deviation and lt;3%
Brightness  uniformity and gt;=97%
Contrast  ratio 5000:1
Max  power  consumption(W) 650
Average  power  consumption(W) 220
scanner 1/32
Frame  change  frequency(HZ) 50-60
Refresh  rate(HZ) 1920
Life  span(hours) 100,000




Features:

1.  Size: 565*2000mm

2.  Lightweight and ultra-thin fashion design, perfect ad playback control.

3.  The LED screen has the advantages of high refresh, high brightness, high contrast of color, and the playback effect is superior to the traditional LCD screen.

4.  Support SD card and U disk playback media, stored program files can be played in a loop.

5.  Support WIFI and 3G/4G mode for maintenance and update of programs.

6.  It can be set to automatically turn on and off every day, without manual maintenance.

7.  Support cluster play and management, agree that the cluster mirror screen can agree to design and update programs, saving time and effort.

8.  The cabinet structure is designed with a modular frame and a metal body for easy installation, disassembly and maintenance.

9.  The exterior of the cabinet is equipped with an acrylic plate to protect the screen body.



Detail images:



Led module picture:

black leds



High Refresh Driver, SMD wide view angle.

It can be used for different type of commecial advertisement, support WIFI, 3G/4G internet connection, very useful.



Our services:
A: 24 Hours After sales support,professional support,remote control and manual book,not only sell display to you,but more support.

B: Real Taiwan Chip + High quality suit, CE,ROHS,FCC certification factory.

C: Sure Dispaly from factory is 100% test done and no any fault,any problem, we will responsibile it.

​D: Welcome to contact us, we will provide you with more supports and services.
