5A DC to DC CC CV Lithium Battery Step down Charging Board Led Power Converter Lithium Charger Step Down Module hong XL4015 E1

SALE 19% OFF

5A DC to DC CC CV Lithium Battery Step down Charging Board Led Power Converter Lithium Charger Step Down Module hong XL4015 E1





















100% Brand New.

  • Size: 5.2 x 2.65 x 1.4cm (L x W x H)

  • Module Properties: non-isolated constant current and voltage module

  • Rectification: non-synchronous rectification

  • Input voltage: 8V-36V

  • Output voltage: 1.25V-32V

  • Output current: adjustable maximum 5A

  • Conversion efficiency: 95% (the highest)

  • Switching frequency: 180KHz

  • Output ripple: 50mV (max) 20M bandwidth

  • Load Regulation: ± 0.5%

  • Voltage Regulation: ± 2.5%

  • Operating Temperature: -40  °c  to +85  °c

Load Regulation: ± 0.5%

Voltage Regulation: ± 2.5%

Operating Temperature: -40 °c to +85 °c
