Precautions
1. Before installing the protection board, the battery should be matched well (the voltage difference between each battery should not be 0.05V, the internal resistance difference is not more than 5mQ, the tolerance is less than 30mAh), the smaller the battery voltage difference, the better the protection board will work. .
2. The batteries are connected in parallel and then connected in series, and the welding is correct (18650 battery nickel spot welding, other batteries are soldered), do not screw, easy to burn the protection board IC.
3. If it is an old battery change board, please pay attention: Please confirm the battery is normal before buying?
4. When installing, use a multimeter to check whether the voltage of each string is the same? The performance failures with a difference of more than 1.0V are: running not far, starting and powering off, charging time is short, basically the battery core problem is more. The failure of the protection board is as follows: the battery cannot be charged, and the battery has a voltage and cannot be discharged.
parameter
Long-lasting discharge current: 2A-9A
Single-cell consumption of battery (self-consumption): ≤3uA
Charging voltage: 3.7V
Charging current: 2A-9A
Overcharge detection voltage: 3.7±0.05V
Overcharge protection delay: I S
Overcharge release voltage: 3.7±0.05V
Over-discharge detection voltage: 2.0-2.1V
Over-discharge detection delay: lO0mS
Over discharge release voltage: 2.3±2.1V
Overcurrent detection voltage: 200±25mV
Overcurrent detection delay: 10mS
Overcurrent detection current: 2A-9A
Overcurrent protection release condition: automatic recovery
Short circuit protection condition: External load short circuit
Short circuit detection delay: 250uS
Short circuit protection release condition: Disconnect load
Main circuit conduction internal resistance: ≤20mΩ
Working current: ≤20uA
Sleep current (current over discharge): ≤20uA
Working temperature: -20 ° C ~ 40 ° C
