Thermal |
|
|
Image Sensor |
VOx Uncooled Focal Plane Arrays |
|
Resolution |
256×192 |
|
Pixel Interval |
12μm |
|
NETD |
Less than 60 mK (25°C,F#=1.1) |
|
Aperture |
F1.0 |
|
Field of View |
35° × 27° (H × V) |
|
Optical |
|
|
Image Sensor |
1/2.8″ 2.0M Pixel CMOS |
|
Resolution |
1920×1080P |
|
Min. Illumination |
Color: 0.005Lux (F1.2, AGC ON), B/W: 0.001 Lux (F1.2, AGC ON) |
|
Field of View |
84° × 45° (H × V) |
|
Focal Length |
4mm |
|
Shutter Speed |
1s to 1/100,000s |
|
White Balance |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Daylight Lamp/Sodium Lamp |
|
Day and amp; Night |
ModeIR cut filter with auto switch |
|
WDR |
80 dB |
|
Feature |
|
|
Bi-spectrum Image Fusion |
Fusion view of thermal view and overlaid details of the optical channel |
|
Picture in Picture |
Combines details of thermal and optical image PIP, overlay thermal image on optical image |
|
Smart Function |
|
|
Face snapping |
Built-in deep learning AI algorithm, Supports simultaneous detection of 20-30 faces |
|
Temperature Measurement |
Support global and local temperature |
|
Temperature Range |
From -15°C to +150°C |
|
Temperature Accuracy |
Target temperature 35°C ^ 38°C ±0.3 °C Target temperature 20°C ^ 33°C ±0.6 °C Target temperature 38°C ^ 50°C ±0.6 °C |
|
Network |
|
|
Main Stream |
Thermal: 25fps(1920 × 1080, 1280 × 720) |
|
Sub Stream |
Thermal: 25fps(704 × 576, 352 × 288) |
|
Video Compression |
H.264 (Baseline/Main/High Profile) /MJPEG/H.265 |
|
Audio Compression |
G .711u/G.711a/G.722.1/MP2L2/G.726/PCM |
|
Protocols |
TCP/IP, ONVIF, GB/T 28181, DHCP, RTP, RTSP, PPPoE, UPnP, UDP |
|
API |
ONVIF (Profile S, Profile G, Profile T), SDK |
|
General |
|
|
Web Client Language |
languages English, Chinese |
|
Power |
DC 12V, 0.65A |
|
Work Temperature/Humidity |
From -20°C to 55°C; Humidity: 95% or Less |
|
Protection Level |
IP67 |
