TFT lcd HD interactive all in one industrial touch screen monitor kiosk17 19 22 inch pc built in CCTV display totem

TFT lcd HD interactive all in one industrial touch screen monitor kiosk17 19 22 inch pc built in CCTV display totem

TFT lcd HD interactive all in one industrial touch screen monitor kiosk17 19 22 inch pc built in CCTV display totem





SPECIFICATION

LCD Dispaly

Model No.

AT-17E

Panel size

17″ TFT-LCD

Maximum resolution

1280*1024

Ratio

4:3

Brightness (nits)

350cd/m2

Contrast

1000:1

Visual angle

178°/178°

Response time

5ms

Life(hrs)

and gt;60,000(hrs)

Touch Panel

Specification

Capacitive Touch

positioning accuracy

±2mm

Touch Media

Finger

Transmittance

≥92%

Glass Hardness

7H

Click Mode

10 points at the same time

Response Time

and lt;=10ms

Life Time

Click life and gt;=60M times

Input and output

HDMI input

1

Audio(L/R) input

1(RCAx2)

WIFI Module

Included

USB

3

RJ45

1

Speaker

2×5W(9Ω)

PC

Motherboard

H81

CPU

Intel i3 4170   3.6Ghz or optional

Memory

DDR3 4G

Hard disk

SATA 500G

Keyboard and Mouse(Optional)

wireless waterproof keyboard and mouse set

Interface

VGA*1,USB*2,RJ45*1

Software environment

Windows XP/ Windows 7/ Windows 2003

Temperature

Working temperature

– 20°C~+80°C

Working humidity

25%~85%

Detailed functions

Video format

MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI

Audio format

Wave/MP3/WMA/AAC

Warranty

1 year

Appearance

Panel color/appearance

Golden / customized

Installation

Wall-mounted or Floor-standing / Optional



cheap capacitive small touch screen monitor 17 inch tablet pc

1)Capacitive touch technology,full HD 1024*768P

2)High performance,No drift, no light points. Fast response.

3)Toughened glass protecting, anti-knocking, water and dust proof.

4) Annotation function on Microsoft Office PowerPoint and Word file.

5)CE,FCC,ROHS are available

Best touch screen, High quality  17inch usb capacitive touch screen panel  ,Welcome your inquiry!





Dimension:













Overview:

BPC series is a cost-effective industrial PC,12~24V power input,compliant many different complex environment; have many I/O port, 1*LAN, 4*USB 2.0, 4*RS232(or 2*rs232/485) audio output, VGA, HDMI port,support Synchronous or asynchronous external display.

Feature:

  • Ø    high bright LCD Screen, resistance/capacitance optional
  • Ø    Isolation communicate port , stable and reliable
  • Ø    electromagnetic resistance grade 3,meet the application requirements of the power industry
  • Ø    Front panel reach NEMA/IP65







Dimension:



Product Description





TFT lcd HD interactive all in one industrial touch screen monitor kiosk17 19 22 inch pc built in CCTV display totem
