Product Description
【True Cat8 Performance】 2Ghz frequency and 40Gbps in data transfer, compliant with ANSI/TIA568.2-D Category 8, ISO/IEC TR11801 Class I, IEC61156-9 Cat.8.1, Flammability rating at UL444 CM or CMR, IEC60332-1-2, IEC60332-3-24, LSZH Acidity: IEC60754-2, Smoke Density: IEC60332-3-24. RoHS supporting 10BASE-T, 100BASE-TX (Fast Ethernet) 1000BASE-T/1000BASE-TX (Gigabit Ethernet), 10GBASE-T (10-Gigabit Ethernet) and 25GBASE-T (40 GbE). Available in 1m, 2m, 3m, and 5m lengths.
【Quality Build】 22AWG solid copper conductor wiring, individually foiled pairs with aluminum shielding and amp; overall cable screen shielding provides the basis for extreme reliability and blazing fast connections. Certified according to specification Class I in according with IOS/IEC 11801-1 Ed. 1.0 up to 2GHz.
【Next Gen】 Next generation 40G network systems are ideal for corporate network systems, datacenters, broadcast stations, media/video servers, and amp; those with extreme high-speed networking needs.
【Highly Compatible】Common RJ45 Port allows you to connect a wide variety of devices. Great for use with: HDBaseT, NAS, VoIP, POE, POE+ (Power Over Ethernet Plus), PC/Mac, Routers, Cable Modems, Printers/Scanners, or entertainment systems like PlayStations, Xbox or for audiophile audio equipment.
【AMPCOM Cares】Backed by a AMPCOM Limited 1-Year Warranty and complimentary premium online support.
AMPCOM Cat8 Ethernet Patch Cable S/FTP 22AWG Screened Solid Cable 2000Mhz(2Ghz) up to 40Gbps with Gold Plated RJ45 Connector for Gaming, Playstation, TV, Xbox, Switch, Router 16ft/5m
-
【True Cat8 Performance】2Ghz frequency and 40Gbps in data transfer, compliant with ANSI/TIA568.2-C.2 Category 8, ISO/IEC 11801：2002 , IEC60754-2 Cat.8.1, Flammability rating at UL444 CM or CMR, IEC60332-1-2, IEC60332-3-24, LSZH Acidity: IEC60754-2, Smoke Density: IEC60332-3-24. RoHS supporting 10BASE-T, 100BASE-TX (Fast Ethernet) 1000BASE-T/1000BASE-TX (Gigabit Ethernet), 10GBASE-T (10-Gigabit Ethernet) and 25GBASE-T (40 GbE).
-
【Quality Build】 22AWG solid copper conductor wiring, individually foiled pairs with aluminum shielding and amp; overall cable screen shielding provides the basis for extreme reliability and blazing fast connections. Certified according to specification Class I in according with IOS/IEC 11801-1 Ed. 1.0 up to 2GHz.
-
【Next Gen】 Next generation 40G network systems are ideal for corporate network systems, datacenters, broadcast stations, media/video servers, and amp; those with extreme high-speed networking needs.
-
【Highly Compatible】Common RJ45 Port allows you to connect a wide variety of devices. Great for use with: HDBaseT, NAS, VoIP, POE, POE+ (Power Over Ethernet Plus), PC/Mac, Routers, Cable Modems, Printers/Scanners, or entertainment systems like PlayStations, Xbox or for audiophile audio equipment.
-
【AMPCOM Cares】Backed by a AMPCOM Limited 1-Year Warranty and complimentary premium online support.
We want to make sure you have a better using experiences with AMPCOM Products. We are always ready and happy to assist.
-
Package content:
-
Cat 8 Ethernet Cable × 1
-
Dust Cap × 2
Industrial Grade CAT8 Ethernet Cable
AMPCOM Cat8 Shielded 22 AWG Patch Cables provide a highly compatible easy to use network solution that features a quality build and amp; superb shielding while meeting ultra-high-speed Cat8 performance expectations and all quality certification standards.
Made in quality materials with the latest technology assure you to use without worry.
Cable Features:
-
Conductor: 22AWG single wire OFC
-
Insulation layer: 0.5mm FM certified PE insulation
-
Foil Shielded: 55μ aluminum foil shield
-
Braided Shielded: 0.12mm 16 * 8 magnesium aluminum
-
Outer Diameter: 8.5 ± 0.3mm Characteristic impedance: 100Ω ± 15%
-
Rated voltage: 30V / Rated temperature: -10 to 75 ° C
|
|
|
|
CAT8 PerformanceWith an improvement of the widely used RJ45, CAT8 is able to support the extreme performance and provide the high speed 4 time that of CAT6A with a bandwidth of 2000Mhz NOTE:The actual speed of a network connection relays on many uncertain factors, such as the cables, and the end devices. |
S/FTP Double Shielded
|
Wide CompatibilityBackwards compatible to Cat 7A, Cat 7, Cat 6A, Cat 6 and Cat 5e cabling products. The Cat8 ethernet is advantageously in TCP/IP and UDP application where correct data information is critical, e.g. 4K and 8K video streaming, high quality music streaming, gaming, data centers and in-building installations |
|
|
|
|
|
|
|
|
CAT8 Industrial Grade Shielded Ethernet Cable |
CAT8 Supreme Series Shielded Ethernet Cable |
CAT8 Premium Series Shielded Ethernet Cable |
CAT7 Flat Shielded Ethernet Cable with Braided |
CAT7 Slim type Shielded Ethernet Cable |
|
|
Transmission Speed |
40Gbps |
40Gbps |
40Gbps |
10Gbps |
10Gbps |
|
Bandwith |
2000Mhz |
2000Mhz |
2000Mhz |
600Mhz |
600Mhz |
|
Shielded |
✓ |
✓ |
✓ |
✓ |
✓ |
|
Wire Gauge |
22AWG |
24AWG |
24AWG |
26AWG |
26AWG |
|
Size |
3ft / 6.6ft / 10ft / 16ft / 26ft / 33ft / 50ft / 66ft / 84ft |
3ft / 5ft / 6.6ft / 10ft / 16ft |
3ft / 6.6ft / 10ft / 16ft |
3ft / 6.6ft / 10ft / 16ft / 26ft / 33ft / 50ft |
3ft / 6.6ft / 10ft / 16ft / 26ft / 33ft / 50ft / 66ft / 100ft |
