Stream In

MPTS/SPTS  over  UDP/RTP, 1000M Base-T Ethernet Interface/ SFP interface

6 * (DVB-S/S-2/C/T/ISDB-T/ATSC) Tuners; 6 * ASI (optional)

BISS Descramble

Maximum 8 programs

Video

Resolution

1920x1080P,1920x1080i,1280x720P, 720x576i, 720x480i

480×576, 544×576, 640×576, 704×576

Trans-coding

4*MPEG2 HD  →  4*MPEG2/H.264 HD ;

4*MPEG2 HD  →  4*MPEG2/H.264 SD ;

8 *MPEG2 SD  →  8 *MPEG2/H.264 SD

4* H.264 HD  →  4*MPEG2/H.264 HD ;

4* H.264 HD  →  4*MPEG2/H.264 SD ;

8* H.264 SD  →  8 *MPEG2/H.264 SD

Rate Control

CBR/VBR

Audio

Trans-coding

MPEG-1 Layer 2, AAC and AC3(Optional) any-to-any or pass through

Sampling rate

48KHz

Bit Rate

64Kbps-384Kbps

Stream Out

8*SPTS and amp; 1*MPTS over UDP/RTP/RTSP, 1000M Base-T Ethernet Interface (UDP/RTP uni-cast / multicast)    /SFP interface

1*ASI (as a copy of one of the 8 SPTS or the MPTS) output, BNC interface

System Function

LCD and amp; Key board control; web NMS management

Ethernet software upgrade

General

Dimensions

430mm×405mm×45mm(WxDxH)

Approx weight

4.8 Kg

Temperature range

 0~45℃(Operation), -20~80℃(Storage)

Power requirements

AC 110V±10%, 50/60Hz or AC 220V±10%,50/60Hz

Power consumption

20W
