Technical parameter:
|
project
|
parameter
|
|
model
|
HC1201-AF |
|
Specifications
|
1200 mm |
|
The maximum width of carving
|
1200 mm |
|
The widest paper for entering
|
1350 mm |
|
speed
|
400 mm/s |
|
Knife pressure
|
（10—600）g |
|
Mechanical resolution
|
0.025mm/step |
|
Buffer memory
|
1Gb |
|
Repeat accuracy
|
0.125mm |
|
electric machinery
|
Stepping Motor Subdivided constant current drive
|
|
Interface type
|
1.compatible RS—232 2.compatible USB |
|
Language format
|
DM/PL、HP/GL |
|
Compatible application software
|
Wentai and other drawing software、CorelDraw
|
|
Liyu engraving machine drive
|
win7 win8 |
|
Steel thorn roller
|
12 |
|
Pressure wheel assembly
|
12 |
|
U disk read
|
support
|
|
Automatic contour cutting
|
support
|
|
Power Supply
|
AC220V, 50Hz |
|
Working environment temperature
|
0 ～ 35℃ |
|
Working environment humidity
|
5% ～ 95% |
The above data are subject to change without prior notice, the interpretation of the power of the company owned by Anhui.
Functional characteristics:
Super high pressure, delicate speed control, diamond grade reflective film cutting.
Large capacity, offline cutting.
liyu cutting drive can compatible with CorelDRAW software, which can realize the knife tool radius compensation, the closed compensation, automatic contour cutting, and other functions, including network sharing cutting machine.
U DISK: support artcut software and other cutting software or CorelDraw software stored in the file “*.PLT”, to achieve the perfect cutting, true offline cutting.
Auto contour cut function：contour cutting precision is high, the probe stability is good, not easy to be affected by the outside.
Half cut to achieve , Max. 25mm:1mm, Min.1mm:1mm.
Auto feeding media：fast response speed on detect paper, high stability.
Collect media：Bigger area on collect the cutting media, Stronger function on keep media clean.
