Best selling Professional High accuracy cutting ploter printing, come with SignMaster software

Best selling  Professional High accuracy cutting ploter    printing, come with SignMaster software

Welcome to come our shop


Model:LIYU-HC1201AF



Note:This model cutting plotter brand is LIYU,with

ARMS,have contour cut function.

This machine include those:
cutting plotter
cutting plotter stand
Pen  core(ballpoint pen):1
Connection cable:1
Power cable:1
USB cable:1
Blade:3
Pen handle:1
Operation manual:1
Sofware:SignMaster 1 set
Warranty:  18 months

Technical parameter:









project





parameter





model



HC1201-AF



Specifications



1200 mm



The maximum width of carving



1200 mm



The widest paper for entering



1350 mm



speed



400 mm/s



Knife pressure



(10—600)g



Mechanical resolution



0.025mm/step



Buffer memory



1Gb



Repeat accuracy



0.125mm



electric machinery





Stepping Motor Subdivided constant current drive





Interface type



1.compatible  RS—232    2.compatible  USB



Language format



DM/PL、HP/GL



Compatible application software





Wentai and other drawing software、CorelDraw





Liyu engraving machine drive



win7  win8



Steel thorn roller



12



Pressure wheel assembly



12



U disk read





support





Automatic contour cutting





support





Power Supply



AC220V, 50Hz



Working environment temperature



0  ~  35℃



Working environment humidity



5%  ~  95%





The above data are subject to change without prior notice, the interpretation of the power of the company owned by Anhui.



Functional characteristics:





Super high pressure, delicate speed control, diamond grade reflective film cutting.



Large capacity, offline  cutting.



liyu cutting drive can compatible with CorelDRAW software, which can realize the knife tool radius compensation, the closed compensation, automatic contour cutting, and other functions, including network sharing cutting machine.



U DISK: support artcut software and other cutting software or CorelDraw software stored in the file “*.PLT”, to achieve the perfect cutting,  true offline cutting.



Auto contour cut function:contour cutting precision is high, the probe stability is good,  not easy to be affected by the outside.



Half cut to achieve , Max. 25mm:1mm, Min.1mm:1mm.



Auto feeding media:fast response speed on detect paper, high stability.



Collect media:Bigger area on collect the cutting media, Stronger function on keep media clean.






Factory show:
