BF209A common rail diesel fuel injector testing machine
Product Description
AM-BF209A COMMON RAIL TEST BENCH
BF209A diesel test bench is designed with the future in mind with its new measurement system that has the ability to test the latest common rail injector technologies for all car and commercial vehicle systems.
It offers you and your workshop super-efficient testing with its short mounting and testing times, which enable four common rail injectors to be tested in less than 15 minutes.
Technical Parameters
|
BF209A common rail diesel fuel injector testing machine
|
|
|
|
Model
|
BF209A
|
|
|
Power
|
4KW
|
|
|
Power supply
|
380V/50HZ/3phrase
|
|
|
The speed of the test bench
|
0～1500 r / min
|
|
|
The continuous injection time
|
0～1000times
|
|
|
Rail pressure
|
0～2300 bar
|
|
|
Pulse width
|
100～3000μs
|
|
|
Fuel oil temperature
|
38±2℃
|
|
|
The test oil filtration rating
|
Les than 5μ
|
|
|
Oil tank capacity
|
50L
|
|
|
The overall size (MM)
|
1400x830x1580(mm)(included wheels)
|
|
|
Weight
|
350kg
|
|
Product details
Product display
